High-speed, high-precision, high-rigidity; heavy-duty, heavy-cutting models, the Y/Z axis adopts 45 wide roller linear rails, and the Z axis adopts a heavy-duty six-slider design. The servo motor is directly connected to the screw through a rigid coupling without backlash, which can ensure the machining accuracy. Even if it is a very complicated work, it can also process sharp corners to ensure the machining accuracy. Each machine tool has been tested with heavy-duty full tools to ensure smooth operation and reliable tool exchange even with heavy-duty tools.

All machines use laser measurement, cutting test, long-term running-in test and strict inspection in accordance with VDI 3441 standard, so that each axis has good repeatability, accurate positioning, and ensures machine accuracy. Renishaw is used to calibrate the roundness and geometric accuracy of the machine to verify and ensure the vertical accuracy of the three-dimensional space.

The sleeve-type spindle design provides 6000/4500rpm gear-driven spindle or belt-type spindle, and the short nose spindle bearing is effectively supported by the bushing and head castings, so the rigidity of the spindle can be greatly improved, and high horsepower can be selected for cooperation 。The spindle motor can show the largest metal removal rate, and the spindle cooling system can reduce the temperature rise of the bearing and extend the life of the spindle.

Japanese shovel technology combined with unique *shaped shovel and Z-shaped oil grooves can produce a uniform oil film on the sliding surface, eliminating floating phenomenon during rapid movement and starting stickiness of cutting feed.The spindle is equipped with spindle oil temperature control system, which can effectively achieve temperature effect.

All machine castings of the machine tool are made of high-quality Meehanite castings, which are annealed to eliminate internal stress. The structure of the machine bed is optimized and the mechanical dynamic rigidity is excellent.

The two-stage transmission gear design can make the main shaft horsepower more smoothly. The transmission gears are all imported from the original package. The chromium-molybdenum alloy steel material is hardened and precision ground. The main shaft runs quietly and smoothly.

A large amount of coolant will rush the processed iron filings to the screw chip conveyors on both sides of the machine, which can easily send the processed iron filings to the outside of the machine quickly, reducing the operator’s wasted non-processing time due to the removal of iron filings. The customer needs to add a chain chip conveyor.
