• It adopts high-torque spindle drive and powerful shaft drive device with high cutting rate.
• The base is the foundation of the whole machine tool and the main supporting part of the saddle and the column.The base of this machine adopts an integralinverted “T” structure,and a considerable number of annular ribs are arranged on the inner walof the base,thereby enhancing the rigidity of the base.Ensure the durabilty of ngidity.
• The base casting is made of high-precision pentahedral gantry in one camping process.which reduces the clamping error and improves the accuracy of the base.
• The column is the supporting part ofthe headstock,which not only has to bear the cutting force in all directions, but also bear the relevant overturning moment.Therefore,the column adopts a double-column ciosed frame structure,and the cavity is provided with Iongtudinal and transverse ring ribs,so that the column has high torsion and bending rigidity;the use of heavy-duty roler guides greaty improves the movement accuracy and rigidity

Features
